Description
Ensure smooth and reliable trailer suspension with the Single Axle Shackle Strap, designed for optimal performance and durability. This shackle strap measures 3.12" eye to eye, providing a precise fit for single axle applications. This shackle strap is one component of the shackle assembly and needs to be paired with the "shackle strap bolt assembly" and two "shackle nuts" to complete one assembly.
- COMMON COMPONENT FOR SINGLE AXLES: With a 3.12" eye-to-eye dimension, this shackle strap provides the correct fit for many single axle leaf spring systems, promoting proper suspension function and stability.
- REFRESH YOUR SUSPENSION: A crucial component in your trailer's leaf spring suspension, this shackle strap helps absorb shocks and maintain consistent axle alignment, contributing to a smoother tow.
- EASY REPLACEMENT: Designed for straightforward installation, this shackle strap allows for quick and efficient replacement, minimizing downtime and getting your trailer back on the road sooner.
Specifications
| Used For | Hardware for Mounting Leaf Spring to Trailer |
|---|---|
| Fits Trailer Type | Universal |
| Fits Trailer Brand | Universal |
| Fits Axle Size | 3,500 - 5,200 lb |
| Eye to Eye Distance | 3.12" |
| Overall Length | 4.38" |
| Hole Size | 9/16" |
| Compatible Shackle Assembly | Single Axle Shackle Strap Bolt Assembly - 3.12" Eye to Eye 05-HKM008-SA |
| Compatible Shackle Nut | Shackle Lock Nut 7/16" 05-HKM010 |
| Compatible Leaf Springs | Double Eye Leaf Spring for 3,500 lb Axle 05-AXSP01 Double Eye Leaf Spring for 5,200 lb Axle 05-AXSP02 |
| Torque Spec | Shoulder Bolt 7/16 Thread: 30-50 ft lbs Non-Shoulder 9/16 Thread: Snug Fit Only. Parts Should Move Freely |
| Cross Reference | 018-012-01 |
